    Separating the deck

    See the previous post for finishing up on making the deck cuts.
    Here are a bunch of pics showing the result of separating the deck from the hull.

    Click image for larger version  Name:	A_IMG_9351.jpg Views:	0 Size:	52.8 KB ID:	188986

    Click image for larger version  Name:	B_IMG_9350.jpg Views:	0 Size:	54.2 KB ID:	188991

    Click image for larger version  Name:	C_IMG_9349.jpg Views:	0 Size:	53.7 KB ID:	188992

    Click image for larger version  Name:	D_IMG_9352.jpg Views:	0 Size:	56.6 KB ID:	188993

    Click image for larger version  Name:	E_IMG_9353.jpg Views:	0 Size:	55.8 KB ID:	188989

    Click image for larger version  Name:	F_IMG_9354.jpg Views:	0 Size:	53.9 KB ID:	188990

    Click image for larger version  Name:	G_IMG_9355.jpg Views:	0 Size:	55.0 KB ID:	188988

    Click image for larger version  Name:	H_IMG_9356.jpg Views:	0 Size:	53.0 KB ID:	188987

    Click image for larger version  Name:	I_IMG_9357.jpg Views:	0 Size:	53.1 KB ID:	188994

    Click image for larger version  Name:	J_IMG_9358.jpg Views:	0 Size:	54.9 KB ID:	188995
    Last edited by Ken_NJ; 07-10-2025, 09:00 AM.

    Comment

    • redboat219
      Admiral

      • Dec 2008
      • 3390

      #77
      Wonder what Bronco had in mind for that "box".
      Too bad, if it was located more midship could it be used as a ballast tank
      Make it simple, make strong, make it work!

      Comment

      • Das Boot
        Rear Admiral

        • Dec 2019
        • 1488

        #78
        Ken, you and David make it look easy. Every time I’ve tried to cut plastic, I just make a melted mess. That’s why I’ve got this Type XXIII unopened, because I’m afraid to try. There was a guy in here a couple years ago that tried doing the same thing with his XXIII, but said he ruined the hulls, and ended throwing them both in the garbage. I wish when Bronco had designed this kit, they would have made the top half of the hull removable. The rest would’ve been a cakewalk. Anyway, good job. Can’t wait to see the end result.
        Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

        Comment

        • Das Boot
          Rear Admiral

          • Dec 2019
          • 1488

          #79
          Ken, I’m kind of lost. I see where you’re doing Dave’s version of the boat, but where does Manfred’s come into play at? I seem to remember Manfred had his as a twist/lock version to access the SD.
          Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

          Comment

          • Ken_NJ
            Captain

            • Sep 2014
            • 974

            #80
            Manfred has his hull sections halves basically bolted together so he can service the rudder area and the torpedo door area. With the bow sections bolted, the aft sections bolted, then the bow and aft sections join in his magnetic joint fashion. Did I explain that enough?

            Comment

            • goshawk823
              Commander

              • Oct 2010
              • 260

              #81
              I have one of these Type XXIIIs that I bought a few years ago because it came with David’s upgrade kit; they are scarce as hen’s teeth. Whomever had this hull butchered the hull cutout, and also glued the tower to the upper hull. I have a second one still in the box that I wanted to build as static display model, but I may have to use it for the R/C version because I think the first one I bought is going to be an unreal amount of work to fix. I’ll scavenge the prop bearing fittings and other parts off David’s upgrade kit from the old hull. I am dreading cutting up the hull even though I have a Zona saw and cutoff wheels for my micro motor. It’s touchy ****; the possibility of melting the plastic is real. As mentioned, this would have been an easy conversion if Bronco would have split the hull longitudinally as part of their design. Following along closely on your progress here, as it looks like your hull separation work came out very well.

              Comment

              • Das Boot
                Rear Admiral

                • Dec 2019
                • 1488

                #82
                Originally posted by Ken_NJ
                Manfred has his hull sections halves basically bolted together so he can service the rudder area and the torpedo door area. With the bow sections bolted, the aft sections bolted, then the bow and aft sections join in his magnetic joint fashion. Did I explain that enough?
                I understood it, but if you want to go on you’re welcome to. Anything RC sub related, I could read all night.
                Last edited by Das Boot; 07-10-2025, 08:16 PM.
                Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

                Comment

                • Subculture
                  Admiral

                  • Feb 2009
                  • 2419

                  #83
                  Avoiding melting is simple enough, keep the cutting speed down, take light cuts and use a very sharp cutting wheel, and brush in a bit of water with some dish washing liquid in as you cut. This will cool the plastic and tool, and the soap reduces friction on the area of the blade that doesn’t do any cutting.

                  Comment

                  • Ken_NJ
                    Captain

                    • Sep 2014
                    • 974

                    #84
                    Forward deck filler

                    For the lack of a better word at the moment, using filler.

                    The Exacto blade width was 20 thousandths. So assuming the cut width is the same.

                    Click image for larger version

Name:	A_IMG_9384.jpg
Views:	38
Size:	51.7 KB
ID:	189011

                    A sheet of 20 thousandths styrene in place causes the weld lines to line up.

                    Click image for larger version

Name:	B_IMG_9383.jpg
Views:	44
Size:	48.6 KB
ID:	189010

                    After some slight sanding of the edge to clean it up, a section of gray styrene was attached with solvent.

                    Click image for larger version

Name:	C_IMG_9385.jpg
Views:	41
Size:	52.8 KB
ID:	189012

                    Click image for larger version

Name:	D_IMG_9386.jpg
Views:	39
Size:	51.7 KB
ID:	189015

                    After the filler piece was sanded down...... and since the cut was just about perfect, there were no gaps between the removable deck and just applied filler piece. I'll probable apply gray Nitro-Stan anyway to fill in any gaps but it will probably be sanded away.

                    Click image for larger version

Name:	E_IMG_9473.jpg
Views:	39
Size:	48.1 KB
ID:	189013

                    A 20 thousandths strip was pre bent and attached to the deck.

                    Click image for larger version

Name:	F_IMG_9471.jpg
Views:	40
Size:	50.4 KB
ID:	189016

                    This strip locates the forward section of the deck into the hull.

                    Click image for larger version

Name:	G_IMG_9472.jpg
Views:	40
Size:	50.9 KB
ID:	189014

                    Comment

                    • He Who Shall Not Be Named
                      Moderator

                      • Aug 2008
                      • 13435

                      #85
                      Originally posted by Subculture
                      Avoiding melting is simple enough, keep the cutting speed down, take light cuts and use a very sharp cutting wheel, and brush in a bit of water with some dish washing liquid in as you cut. This will cool the plastic and tool, and the soap reduces friction on the area of the blade that doesn’t do any cutting.
                      And mount the disc with the teeth pointing backwards.
                      Who is John Galt?

                      Comment

                      • Ken_NJ
                        Captain

                        • Sep 2014
                        • 974

                        #86
                        Once the deck was cut away from the hull, the deck sort of compressed or expanded so that it did not meet correctly with the hull. Here I marked the hull profile on paper.

                        Click image for larger version  Name:	A_IMG_9468.jpg Views:	0 Size:	49.1 KB ID:	189020

                        And compared it to the deck.

                        Click image for larger version  Name:	B_IMG_9469.jpg Views:	0 Size:	48.8 KB ID:	189019

                        A piece of acrylic was clamped to the deck. The clamp was tightened until the deck lined up with the profile on paper. Then it was flipped and solvent applied.

                        Click image for larger version  Name:	C_IMG_9470.jpg Views:	0 Size:	52.4 KB ID:	189022

                        Here you can see the clear acrylic which aligned the edges of the deck to the edges of the hull.

                        Click image for larger version  Name:	D_IMG_9471.jpg Views:	0 Size:	50.4 KB ID:	189021

                        Comment

                        • Ken_NJ
                          Captain

                          • Sep 2014
                          • 974

                          #87
                          Hull filler/shim

                          The hull edge was sanded with an emory board to clean up the edge. Strips of 30 thousandths styrene was cut from the sheet and sanded prior to adhesion to the hull edge. Solvent was applied to both edges to soften the styrene and placed in this setup and more solvent was applied. Once the solvent set and the hull removed from the setup, more solvent was applied from the inside of the hull.

                          Click image for larger version

Name:	A_IMG_9387.jpg
Views:	49
Size:	55.0 KB
ID:	189024

                          Closeup.

                          Click image for larger version

Name:	B_IMG_9388.jpg
Views:	47
Size:	52.6 KB
ID:	189027

                          Finished applying filler pieces.

                          Click image for larger version

Name:	C_IMG_9390.jpg
Views:	45
Size:	51.6 KB
ID:	189030

                          Click image for larger version

Name:	D_IMG_9391.jpg
Views:	42
Size:	52.1 KB
ID:	189031

                          Sanding the inside. After rough sanding with the Dremel, finished with an emory board.

                          Click image for larger version

Name:	E_IMG_9392.jpg
Views:	45
Size:	42.9 KB
ID:	189025

                          Progress

                          Click image for larger version

Name:	F_IMG_9425.jpg
Views:	44
Size:	50.5 KB
ID:	189026

                          Finished edge

                          Click image for larger version

Name:	G_IMG_9427.jpg
Views:	44
Size:	49.5 KB
ID:	189029

                          Closeup

                          Click image for larger version

Name:	H_IMG_9428.jpg
Views:	43
Size:	50.6 KB
ID:	189028

                          After the side edges was done, progressed to sanding the top edge to make sure it was horizontal side to side and that the deck met correctly to the top of the decks hull.

                          Click image for larger version

Name:	I_IMG_9467.jpg
Views:	44
Size:	50.0 KB
ID:	189032

                          I was carful enough that I could get the weld line sanded into the shim.

                          Click image for larger version

Name:	J_IMG_9429.jpg
Views:	46
Size:	48.7 KB
ID:	189034

                          Looking through a magnifying glass.

                          Click image for larger version

Name:	K_IMG_9451.jpg
Views:	43
Size:	45.5 KB
ID:	189033

                          Finished. Couldn't get the seam any tighter than this.

                          Click image for larger version

Name:	L_IMG_9474.jpg
Views:	43
Size:	49.4 KB
ID:	189036

                          Click image for larger version

Name:	M_IMG_9540.jpg
Views:	44
Size:	49.1 KB
ID:	189035

                          Comment

                          • He Who Shall Not Be Named
                            Moderator

                            • Aug 2008
                            • 13435

                            #88
                            Beautiful process and work. Almost 'seamless'.

                            I hate you!

                            David
                            Who is John Galt?

                            Comment

                            • Das Boot
                              Rear Admiral

                              • Dec 2019
                              • 1488

                              #89
                              Primo work.
                              Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

                              Comment

                              • redboat219
                                Admiral

                                • Dec 2008
                                • 3390

                                #90
                                Originally posted by Subculture
                                Avoiding melting is simple enough, keep the cutting speed down, take light cuts and use a very sharp cutting wheel, and brush in a bit of water with some dish washing liquid in as you cut. This will cool the plastic and tool, and the soap reduces friction on the area of the blade that doesn’t do any cutting.
                                Click image for larger version

Name:	images (46).jpg
Views:	69
Size:	63.0 KB
ID:	189040 Great tip about using soap as lubricant.
