    #3151
    Originally posted by redboat219
    Click image for larger version

Name:	kXz5yn.jpg
Views:	216
Size:	47.9 KB
ID:	188922
    after retiring Superman takes up building RC model submarines
    I can just see fat-ass trying to tear out of a phone-booth while shedding shirt, tie, and glasses.
    Who is John Galt?

    Comment

    • TAGood827
      Lieutenant, Junior Grade

      • May 2023
      • 10

      #3152
      [QUOTE=He Who Shall Not Be Named;n188920]
      Originally posted by TAGood827

      Standing by.

      David
      So after watching the videos you posted, I have my first questions.

      During the video of the 1/128 Moebius kit in the big pool, I believe you said you thought you should add some bow planes to the front of the Seaview as she tends to dive with that big wing in the front.

      Did you do that? If so, was it a cut of the wing and how wide did you go?

      That's something I will have to plan for in modifying my Ken Lane files.

      Also, I think it might be best if I create a new topic based solely on the Ken Lane Seaview so as not to disrupt this forum.


      Tim

      Comment

      • ffr2608
        Commander

        • Oct 2009
        • 338

        #3153
        My favorite photo is Dave in the red shirt. Holding the Seaview like he’s slapping a bass guitar.

        Comment

        • He Who Shall Not Be Named
          Moderator

          • Aug 2008
          • 13404

          #3154
          [QUOTE=TAGood827;n188961]
          Originally posted by He Who Shall Not Be Named

          So after watching the videos you posted, I have my first questions.

          During the video of the 1/128 Moebius kit in the big pool, I believe you said you thought you should add some bow planes to the front of the Seaview as she tends to dive with that big wing in the front.

          Did you do that? If so, was it a cut of the wing and how wide did you go?

          That's something I will have to plan for in modifying my Ken Lane files.

          Also, I think it might be best if I create a new topic based solely on the Ken Lane Seaview so as not to disrupt this forum.


          Tim
          I've assembled four of these wonderful Mobius kits, but only one was outfitted with practical 'bow planes'. The other three -- assemble and profiting from lessons learned on the first, bow plane equipped unit --only required practical INDEPENDANT (and that is an important distinction) stern planes and fairwater planes. The practical bow planes turned out to be an ugly and redundant means of controlling the submarines pitch angle. Let let the following illustrations make my argument:

          That first SEAVIEW was totally uncontrollable in pitch once achieved submerged trim; any advance of the throttle and the shovel-bow pushed the nose down and control could not be regained without going all-back-MF'r. I retrofitted the bow planes, and only with that rather ugly arrangement (see below picture) could I control the boats pitch angle. The stern planes and bow planes were mechanically linked together and worked in unison to rotate the boat about the pitch axis


          Click image for larger version  Name:	DMS2FF.jpg Views:	0 Size:	63.8 KB ID:	188974

          Ellie and I produced an entire range of fittings kits for this subject. Here you see the bow planes, control horns and a portion of the stern plane-bow plane push rods.

          Click image for larger version  Name:	DSCN0071 (2).jpg Views:	0 Size:	29.3 KB ID:	188972

          Though the retro-fit bow planes continued the compound curved lives at the tips of the 'manta fins', once they assumed any angle the entire aesthetics of the submarine were ruined!

          Click image for larger version  Name:	DSCN0065.jpg Views:	0 Size:	43.9 KB ID:	188971

          And here is the linkage that ran from the bow planes to the stern planes. As to the dimensions of the bow planes -- those were driven by the engraved outline represented on the kit parts by deeply engraved lines. Just follow the lines and you have the shape of the bow planes.

          Click image for larger version  Name:	DSCN0084.jpg Views:	0 Size:	21.5 KB ID:	188973

          The stern portion of the bow-stern plane linkage.

          Click image for larger version  Name:	DSCN0055.jpg Views:	0 Size:	46.1 KB ID:	188970

          Through extensive testing, evaluation, and experiment I came up with the fix: pre-setting the stern planes at a slight 'rise' angle and incorporation of a fixed stator van in the bottom of the nozzle to also produce a pitch-up moment whenever the pump-jets were pushing water. These two steps eliminated the need for the bow planes.

          Click image for larger version  Name:	Img0408.jpg Views:	0 Size:	52.0 KB ID:	188975

          Click image for larger version

Name:	Img0410.jpg
Views:	132
Size:	47.9 KB
ID:	188976



          I have no problem sharing my thread -- the objective is to interact with you guy's, not to spout off without challenge from on high.

          David
          The Horrible

          Who is John Galt?

          Comment

          • He Who Shall Not Be Named
            Moderator

            • Aug 2008
            • 13404

            #3155





























            Who is John Galt?

            Comment

            • Das Boot
              Rear Admiral

              • Dec 2019
              • 1488

              #3156
              I’ve never seen anyone perfect parts of the boat that will never be seen by anyone as you do. For some reason I’m the same way. I take pride in my limber holes being correct and square. It’s kind of weird, isn’t it? I would even say anal. I’m the same way with ham radio equipment. If I see a used piece of gear, and it’s got one smudge on it, I won’t buy it.
              Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

              Comment

              • He Who Shall Not Be Named
                Moderator

                • Aug 2008
                • 13404

                #3157
                Originally posted by Das Boot
                I’ve never seen anyone perfect parts of the boat that will never be seen by anyone as you do. For some reason I’m the same way. I take pride in my limber holes being correct and square. It’s kind of weird, isn’t it? I would even say anal. I’m the same way with ham radio equipment. If I see a used piece of gear, and it’s got one smudge on it, I won’t buy it.
                It's not the destination so much as it's all about the getting there.
                Who is John Galt?

                Comment

                • JHapprich
                  Captain

                  • Oct 2017
                  • 883

                  #3158
                  Originally posted by He Who Shall Not Be Named

                  It's not the destination so much as it's all about the getting there.
                  Absolutely!

                  Comment

                  • Das Boot
                    Rear Admiral

                    • Dec 2019
                    • 1488

                    #3159
                    Originally posted by He Who Shall Not Be Named

                    It's not the destination so much as it's all about the getting there.
                    Ralph Waldo Emerson?
                    Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

                    Comment

                    • He Who Shall Not Be Named
                      Moderator

                      • Aug 2008
                      • 13404

                      #3160






















































                      Who is John Galt?

                      Comment

                      • JHapprich
                        Captain

                        • Oct 2017
                        • 883

                        #3161
                        What kind of model are you performing repairs on in the last pictures? Victor III/Akula semiscale?

                        Comment

                        • He Who Shall Not Be Named
                          Moderator

                          • Aug 2008
                          • 13404

                          #3162
                          Originally posted by JHapprich
                          What kind of model are you performing repairs on in the last pictures? Victor III/Akula semiscale?
                          My first r/c submarine. Now in the care of its current (third) owner, Jake brought it over for repairs and a new paint-job. This old girl is over 35 years old.

                          Who is John Galt?

                          Comment

                          • He Who Shall Not Be Named
                            Moderator

                            • Aug 2008
                            • 13404

                            #3163






























                            Who is John Galt?

                            Comment

                            • Das Boot
                              Rear Admiral

                              • Dec 2019
                              • 1488

                              #3164
                              I don’t think I’ve ever seen you use a gloss color. Also, that particular shade is a new one on me. Excellent build.
                              Of the approximately 40,000 men who served on U-boats in WWII, it is estimated that around 28,000 to 30,000 lost their lives.

                              Comment

                              • He Who Shall Not Be Named
                                Moderator

                                • Aug 2008
                                • 13404

                                #3165
                                Originally posted by Das Boot
                                I don’t think I’ve ever seen you use a gloss color. Also, that particular shade is a new one on me. Excellent build.
                                Base colors go on glossy, they'll be wet-sanded, weathered, markings, and finally given a well flattened clear-coat at the end.

                                Click image for larger version

Name:	022 - Copy.jpg
Views:	67
Size:	39.4 KB
ID:	189075
                                Who is John Galt?
