    #76
    Amazing work. The many hours put into the CAD model really shows. Can’t wait to see more.

    Comment

    • rwtdiver
      Vice Admiral
      • Feb 2019
      • 1768

      #77
      Originally posted by DrSchmidt
      Really nothing special....Elegoo Mars, Anycubic ABS-Like resin, and Chitubox with standard settings. For the bove prints I let Chitubox do all the supports without any editing.
      DrSchmidt!

      Thank you very much for the return information! Again, can't say enough about your work!!

      Rob
      "Firemen can stand the heat"

      Comment

      • DrSchmidt
        Captain
        • Apr 2014
        • 919

        #78
        Still working on details of the interior of the Type XXIII for my 1:35 Bronco Kit....."Zentrale" with the dive plane controls.
        Click image for larger version

Name:	Zentrale-6.jpg
Views:	746
Size:	72.8 KB
ID:	148072

        Comment

        • DrSchmidt
          Captain
          • Apr 2014
          • 919

          #79

          Still designing the Type XXIII interior. Putting the finishing touches on the ventilation ducts and the ventilation manifold for the batteries. During charging the batteries produced hydrogen that had to be removed by the ventilation system. So there were four tubes running above the battery cells that collected the hydrogen though tiny tubes that were connected to the collection tubes. Tedious work....


          Click image for larger version

Name:	Bateryvent-01.jpg
Views:	625
Size:	74.5 KB
ID:	148255

          Click image for larger version

Name:	Bateryvent-02.jpg
Views:	624
Size:	69.6 KB
ID:	148256

          Comment

          • DrSchmidt
            Captain
            • Apr 2014
            • 919

            #80

            Continuing with the interior and equipment of the torpedo room for my 1:35 Bronco XXIII


            Click image for larger version

Name:	Bugraum.jpg
Views:	619
Size:	76.0 KB
ID:	148570

            Comment

            • DrSchmidt
              Captain
              • Apr 2014
              • 919

              #81
              Designing the hatches for my Txpe XXIII submarine project. Even with blueprints one can spend a few evenings to get them right...

              Click image for larger version

Name:	luke1.jpg
Views:	607
Size:	74.9 KB
ID:	148709
              Click image for larger version

Name:	luke2.jpg
Views:	582
Size:	74.8 KB
ID:	148710

              Comment

              • jphatton
                Lieutenant
                • Jan 2021
                • 84

                #82
                Thanks very much for posting the step by step progress on your CAD and 3D printed model interior. The level of research and effort that has gone into this project si very impressive.

                Indeed one of the thing's of I've found very satisfying with CAD work is translating drawings, photos and often a bit of guesswork into a 3 dimensional model. As you note this often this takes a few iterations to get it right.

                Out of curiosity what CAD software are you using?

                Comment

                • DrSchmidt
                  Captain
                  • Apr 2014
                  • 919

                  #83
                  ViaCad Pro

                  Comment

                  • DrSchmidt
                    Captain
                    • Apr 2014
                    • 919

                    #84
                    Conning tower. Hatch done, next attack periscope. There are plenty photos but all look differet. The XXIII plans help a little bit and I found some blurry cross sections. So what I show here is my best guess approxiamtion.

                    Click image for larger version

Name:	periskop4.jpg
Views:	588
Size:	91.8 KB
ID:	148778

                    Click image for larger version

Name:	periskop1.jpg
Views:	590
Size:	84.9 KB
ID:	148781
                    Attached Files

                    Comment

                    • DrSchmidt
                      Captain
                      • Apr 2014
                      • 919

                      #85
                      Type XXIII submarine: That was a complicated one.....the cable pull mechanism of the periscope. The periscope was raised and lowered by a cable winch in the control room. The cable ran over various pulleys to the periscope. Intricate arrangement under the roof of the conning tower.

                      Click image for larger version

Name:	Turm.jpg
Views:	577
Size:	64.2 KB
ID:	148842


                      Click image for larger version

Name:	Sehrohr.jpg
Views:	546
Size:	89.2 KB
ID:	148843

                      Comment

                      • DrSchmidt
                        Captain
                        • Apr 2014
                        • 919

                        #86
                        A Type XXIII submarine conning tower. Adding bits and pieces....speaking tubes, switch boxes, plugs and rheostates.A Type XXIII submarine conning tower. Adding bits and pieces....speaking tubes, switch boxes, plugs and rheostates.

                        Click image for larger version

Name:	Turm-2.jpg
Views:	556
Size:	73.4 KB
ID:	148893

                        Comment

                        • DrSchmidt
                          Captain
                          • Apr 2014
                          • 919

                          #87
                          Added the ladder and some junction boxes. Fixture for the lamp and cabling, the the CAD model of the conning tower for my 1:35 Bronco XXIII submarine kit is done.

                          Click image for larger version

Name:	Screenshot 2021-04-10 at 12.59.56.png
Views:	556
Size:	126.4 KB
ID:	148952
                          Click image for larger version

Name:	Turm-2.jpg
Views:	506
Size:	78.0 KB
ID:	148953

                          Comment

                          • DrSchmidt
                            Captain
                            • Apr 2014
                            • 919

                            #88
                            Conning tower done....the wiring of the switches and boxes in the isnide is a but guesswork, but it makes sense. Sits comfortably on the control room....Click image for larger version

Name:	Zentrale-7.jpg
Views:	503
Size:	69.5 KB
ID:	149290

                            Comment

                            • DrSchmidt
                              Captain
                              • Apr 2014
                              • 919

                              #89
                              Working on the deep bilge pump of the Type XXIII. It was made by Klein, Schanzlin & Becker (KSB) an to my knowlege it was a two cylinder double-action piston pump with cross heads. With respect to how it looked....few information on that side. Tried to get info from KSB, but no answer. I know that in the stren room of the type XXI the same type of pump was installed, so I took it from there....I guess it's close but becomes guesswork in the lower parts.

                              Click image for larger version

Name:	Screenshot 2021-05-12 at 18.12.40.jpg
Views:	433
Size:	92.9 KB
ID:	149791

                              Comment

                              • DrSchmidt
                                Captain
                                • Apr 2014
                                • 919

                                #90
                                Progress on the Type XXIII submarine galley. Added the activated-charcoal filter for the fresh water faucet right to the sink and the respective piping. Additional work on the ventilation ducts and detail work on the electrically heated pot. Getting there.....

                                Click image for larger version

Name:	Küche.jpg
Views:	383
Size:	65.9 KB
ID:	150382Click image for larger version

Name:	Bugraum-04.jpg
Views:	367
Size:	81.8 KB
ID:	150383

                                Comment
