The British T Class 1:72 scale

Collapse
X

  • Time
  • Show
Clear All
new posts

  • Kazzer
    replied
    I coated the inside of the mold and the plug with another coat of Release Wax

    Click image for larger version

Name:	IMG_0370.jpg
Views:	1
Size:	89.3 KB
ID:	65561

    Next, I installed a piece of steel rod. Actually, it was one of those rods used in the garden for holding up flowers.
    Click image for larger version

Name:	IMG_0373.jpg
Views:	1
Size:	92.1 KB
ID:	65563
    (The rod is hard to see as it's dark green, just to the left of the MMDF board)
    Pouring the resin

    Click image for larger version

Name:	IMG_0371.jpg
Views:	1
Size:	91.3 KB
ID:	65562

    Adding the sand
    Click image for larger version

Name:	IMG_0375.jpg
Views:	1
Size:	90.7 KB
ID:	65564

    Pouring the mix into the mold

    Click image for larger version

Name:	IMG_0376.jpg
Views:	1
Size:	85.7 KB
ID:	65565

    AND!!!!!! Ta!!! Daaaa!

    Click image for larger version

Name:	IMG_0379.jpg
Views:	1
Size:	92.8 KB
ID:	65567

    It's done!!!!!!!

    I rattled the mold on the table for a minute or so, to help the resin settle.

    Until - tomorrow. Patience!
    Attached Files
    Last edited by Kazzer; 12-13-2011, 04:10 AM.

    Leave a comment:


  • Kazzer
    replied
    Click image for larger version

Name:	IMG_0369.jpg
Views:	1
Size:	89.4 KB
ID:	65549

    These long thin models are a real pain to photograph well.

    On the left, I've screwed the MMDF board on, then caulked the joint to the hardboard. On top of the model is a 1/4" thick section of MDF contoured to fit the boat. I put a thin line of latex caulk on the underside to seal it. Then I ran a wet acid paintbrush over all the caulk to smooth it out. We'll let that set up tonight, then I'll do the MMDF end caps and - we're almost ready to pour!!!!!!!! Egg-ziting izn't it!

    Leave a comment:


  • Kazzer
    replied
    The hardboard gets all the edges along the plug filled in with clay. Then a coat of Wood Sealer.


    Click image for larger version

Name:	IMG_0362.jpg
Views:	1
Size:	89.6 KB
ID:	65544

    A formed section of 1/4" MDF is sealed with Wood Sealer and then tacked into position atop the plug with latex caulk.

    Click image for larger version

Name:	IMG_0364.jpg
Views:	1
Size:	87.1 KB
ID:	65545

    The MMDF board (laying flat) has been coated with wax. It will be screwed into its vertical position after sealing with PVA.
    Attached Files

    Leave a comment:


  • oztruck
    replied
    The eyes of the world are upon you. Just luv the old pommy boats.

    Leave a comment:


  • Kazzer
    replied
    I've managed to do a little more to the plug. I guess the most difficult thing was trying to figure out exactly how I was going to make the molds. Seeing as my sand/epoxy molds idea seems to be a winner, then how to actually get this puppy done was a bit of a worry. i have a lot of money invested in the plug and I didn't really want to ruin the thing.

    So, here is my 'cunning plan' (to quote Baldrick -Blackadder)

    Click image for larger version

Name:	IMG_0358.jpg
Views:	2
Size:	87.9 KB
ID:	65541

    I cut a board of Melamine MDF (now referred to as MMDF in future) about 1" longer and wider than the plug. I already had a strip of MDF cut to the profile of the keel, so I hot glued that to the center-line of the MMDF, then mounted the plug on top. I secured it in place with wooden blocks cut 1/8" lower than the waterline, which ran parallel with the keel.
    Then I shaped a strip of hardboard to the edge of the boat along the waterline and hot glued it on top of the blocks.

    Next, comes the sealing of that joint with modelers clay, and the installation of the MDF board cut to go on top of the plug. This will hopefully give me the first quarter section of the four molds.

    On reflection, I could have left those darned torpedo tubes on! Hindsight is a wonderful thing!

    The plug has been waxed and sprayed with a couple of coats of PVA, but I intend to treat each section again, prior to pouring the epoxy slurry.

    Leave a comment:


  • Kazzer
    replied
    Originally posted by greenman407
    If I did my math right thats 46" long. Is that right?
    274'/12 = 3288" 3288/72 =45.66"

    Leave a comment:


  • greenman407
    replied
    If I did my math right thats 46" long. Is that right?

    Leave a comment:


  • Rpmtech1
    replied
    OMG, what a glass layup nightmare making those hulls will be.

    Leave a comment:


  • He Who Shall Not Be Named
    replied
    Mike,

    I strongly suggest you make this tool with a rubber glove-mold. That deep draft area between tank top and external torpedo tube fairing is a sure point of entrapment should you go the hard-shell approach.

    Concentrate on cleaning up the master then turn it over to me -- later this year after I've dug myself out of the current work-load -- for tool making. And by then you will have secured enough detail dope for me to detail the master with all the panel, weld lines, limber holes, and what-not's that a rubber tool can capture with exacting detail. Let's do this beauty justice.

    I have spoken!


    David,

    Leave a comment:


  • Kazzer
    replied
    I've asked the guys over at the Barrow-In-Furness Submariners site for any information they can help with on the T Class. Lofty was kind enough to offer up the following valuable information.

    have look at http://www.rnsubs.co.uk/Dits/Articles/ds48.php

    Section 4a HMS TABARD , there are plenty of GIII pics on the web, but this is an unusual one as it shows clearly the stern tubes with the doors open.

    I seem to have got it from U-Boat net . Might be bigger there .

    Also have a look at http://www.rnsubs.co.uk/Boats/BoatDB...416&flag=class

    The DATA BASE for the T class on this web site.

    Dorset S/ms gallery http://www.dorsetsubmariners.org.uk/gallery/album.php?album=T Boats

    It's also interesting to see John Lambert's Submarine plans as he's documented the Slippery Ts.

    Leave a comment:


  • Kazzer
    replied
    The Plug progresses.

    Click image for larger version

Name:	late july 009.jpg
Views:	1
Size:	94.4 KB
ID:	63393Click image for larger version

Name:	late july 010.jpg
Views:	1
Size:	92.4 KB
ID:	63394Click image for larger version

Name:	late july 011.jpg
Views:	1
Size:	93.9 KB
ID:	63395Click image for larger version

Name:	late july 012.jpg
Views:	1
Size:	24.8 KB
ID:	63396Click image for larger version

Name:	late july 013.jpg
Views:	2
Size:	28.4 KB
ID:	63397

    We're one step closer. Next, to make the molds.

    Leave a comment:


  • gunther
    replied
    p.s. if i had know that rick was building one of the "t" class i would have ordered that instead of the "kilo" i have coming down under..but still happy im getting a great sub"..

    Leave a comment:


  • gunther
    replied
    ur first photo of a "t" class is how i remember them. they would exercise with our navy down here in newzealand..(mid 50's)
    after exercising, they would do ports of call, the one that was here the most was HMS TELEMACHUS.
    my dad being ex navy would take me down and i would spend an hour or to playing up in the conning tower whilst he would be down below having a drink or two before taking some of the crew away for a rabbit shoot, which would be consumed that night along with more beer and whiskey at our place..

    Leave a comment:


  • Rpmtech1
    replied
    Well, I wish me and MR M were not so screwed in the time department. I think, and you know that we have enough to do!

    Look forward to seeing this.

    Leave a comment:


  • Kazzer
    replied
    Originally posted by Rpmtech1
    Holy smokes he's building a plug.... :)

    Nope! Not me! I'm paying for it to be done. I am going to try to make the molds from the remaining model I have for the m1

    Yes, there will be more than one - lots more hopefully.

    Leave a comment:
